AC Fan

Product ID: SJ9225LA2SAT (L)

Axial AC Fan - SJ9225

large

Click here for details.

SJ9225LA1BAT is a 220V AC Fan,its square aluminum frame with 92mm, its thickness with 25mm, plastic blade, ball bearings, low air speed, can provide 2.90mm faston to be terminal type or leadwire type.

Specifications:

Square Frame : 92 mm * 92 mm
Housing Thickness : 25 mm
Bearing System : Sleeve
Rated Vottage(V) : 220 / 240
Freq.(hz) : 50 / 60
Current(A) : 0.14 / 0.12
Input Power(W) : 12 / 9
Speed(RPM) : 1900 / 2400
Air Flow(m3/min) : 0.57 / 0.70
Static Pressure(lnch-H2 o) : 0.10 / 0.14
Noise Level(db-A) : 27 / 31

Certificate:

CE
TUV -LVD
TUV-EMC
UL
cUL
CCC

Model	Part No.	Bearing System	Rated Voltage	Freq.	Current	Input Power	Speed	Air Flow	Static Pressure	Noise Level
Model	Part No.	Bearing System	( V )	( Hz )	( A )	( W )	(RPM)	(m3/min)	(lnch-H2 o)	(db-A)
SJ9225	SJ9225HA1BAT (L)	Ball	110/120V	50/60	0.14/0.12	12/9	2600/3100	0.93/1.13	0.18/0.26	32/36
	SJ9225HA1SAT (L)	Sleeve	110/120V	50/60	0.14/0.12	12/9	2600/3100	0.93/1.13	0.18/0.26	32/36
	SJ9225HA2BAT (L)	Ball	220/240V	50/60	0.07/0.06	13/10	2500/3000	0.93/1.13	0.18/0.26	32/36
	SJ9225HA2SAT (L)	Sleeve	220/240V	50/60	0.07/0.06	13/10	2500/3000	0.93/1.13	0.18/0.26	32/36
	SJ9225LA1BAT (L)	Ball	110/120V	50/60	0.14/0.12	12/9	1900/2400	0.57/0.70	0.10/0.14	27/31
	SJ9225LA1SAT (L)	Sleeve	110/120V	50/60	0.14/0.12	12/9	1900/2400	0.57/0.70	0.10/0.14	27/31
	SJ9225LA2BAT (L)	Ball	220/240V	50/60	0.07/0.06	13/10	1800/2400	0.27/0.70	0.10/0.14	27/31
	SJ9225LA2SAT (L)	Sleeve	220/240V	50/60	0.07/0.06	13/10	1800/2400	0.27/0.70	0.10/0.14	27/31

Main Products:
AC cooling fan,AC axial fan,Fan guard
