Product ID: WCM-II

borescope

WCM series Industrial Digital Borescope is a new detection equipment with high quality after the fiberscope appear. It is a new product with the technology which combine electron, optical, precision machinery together. Super fine digital probe plus design of portable make the product to be one of the most advanced Borescopes in the world. It has a lot features such as small size, light weight, and easy to carry, easy to use, high-definition images, cost-effective and so on. Especially it can detect the narrow curved space which other equipment could not enter in.And It is widely used in many fields, such as machinery, chemical, aviation, security, police and other areas.
SPECIFICATION
Sensor 1/10” Remote Head Camera System
Head diameter 4mm diameter
Working length 1m,2m,3m (Optional)
Head size Φ4.2mmX12.5mm
Forward view 2 ways of articulation
Bending angle 90°～110°
Light source LED / Halogen Lamp
White balance Auto/Manu
Output AV / S-Video, USB2.0 (Optional)
Electrical source Portable besides battery or Rechargeable battery
Display 5.2” color LCD
Optics lens Focus lens
TV Line 480 line
Video format PAL / NTSC
Weight < 1 kg
Image record Video record, deposit, catch (Optional)

Features:

• Sensor
• 1/10” Remote Head Camera System
• Head diameter
• 4mm diameter

• Minimum Order: 1et
