1 Material to be Rolled: Q235, Prepainted steel Coil
2 Thickness To be Rolled: 0.3-0.8mm
3 Coil Width: 1200mm
4 ID of the Coi: ф508-600mm
5 Capacity of the Decoiler: 5T
6 Main Power: 5Kw
7 Power of Hydraulic Cutter: 3Kw
8 Reducer BWY39-58-15 Cycloid Pin
9 Roll Stand: 19
10 Material of Roller: GCr15, HRC58-62, Chrome plated
11 Material of the Shaft: 40Cr
12 Material of the Blade: Gr12, Heat treated
13 Approxemate Dimension: 9m*1.2m*1.3m
14 Weight: 7.5T
2 Thickness To be Rolled: 0.3-0.8mm
3 Coil Width: 1200mm
4 ID of the Coi: ф508-600mm
5 Capacity of the Decoiler: 5T
6 Main Power: 5Kw
7 Power of Hydraulic Cutter: 3Kw
8 Reducer BWY39-58-15 Cycloid Pin
9 Roll Stand: 19
10 Material of Roller: GCr15, HRC58-62, Chrome plated
11 Material of the Shaft: 40Cr
12 Material of the Blade: Gr12, Heat treated
13 Approxemate Dimension: 9m*1.2m*1.3m
14 Weight: 7.5T
Features
.wall panel machineMain Products
roll forming machine, metal roofing machine, metal forming machine
