Link Motion Press Machine
Product ID: LP-160
"LP" link press is available to first move the slide toward the work piece at high speed, and then get the work done at low speed before quickly retrieving the slide. As the slide slows down upon moving to the working zone during the stroke, the vibration, noise, and heat generated from the friction between the work piece and die are much less, when compared with those crank presses. Consequently, die service life is prolonged and operating environment is improved as well. Further, upon drawing, the effective working area is wider than that of crank press, thus reducing the pressing processes.
| Model | Capacity | stroke | weight | dimension |
|---|---|---|---|---|
| LP-80 | 80Tons | 90~150m.m. | 7,500kgs | 1450 x 2010 x 3195mm |
| LP-120 | 120Tons | 110~180m.m. | 11,200kgs | 1580 x 2180 x 3660mm |
| LP-160 | 160Tons | 120~200m.m. | 17,500kgs | 1775 x 2485 x 4010mm |
| LP-200 | 200Tons | 130~220m.m. | 23,000kgs | 1920 x 2765 x 4290mm |
Main Products:
Hot Forging, Cold Forging, Forming Machine, Forging Press, Forging Machine, Roll Forging Machine, Warm Forging
