Features:
**This relief valve is a combination of are employed the pressure control valve combine with reach system pressure and the system pressure & unloading reaches the setting by the solenoid valve action for satisfying the system action requirement.
**These models bring the feature of low noise and large flow rate characters.
**The balanced piston type pressure control valve has reformed by pressures & flows and adjusting closed, stable & sensitive for action.
**The vent can be connected and controlled remotely.
Model numbers:
Gasket type: BSHG-06 & BSHG-10
Specifications:
**Port Size:
BSHG-06: 3/4”
BSHG-10: 1-1/4”
**Max. Flow Liter/min
BSHG-06: 250
BSHG-10: 500
**Weight
BSHG-06: 7.8kg
BSHG-10: 12.6kg
** Bolt Size
BSHG-06: M16x80x4pcs
BSHG-10: M20x90x4pcs
**Max. pressure: 350 kgf/cm2
**Pressure Adjustment Range from 7 – 210 (kgf/cm2)
**This relief valve is a combination of are employed the pressure control valve combine with reach system pressure and the system pressure & unloading reaches the setting by the solenoid valve action for satisfying the system action requirement.
**These models bring the feature of low noise and large flow rate characters.
**The balanced piston type pressure control valve has reformed by pressures & flows and adjusting closed, stable & sensitive for action.
**The vent can be connected and controlled remotely.
Model numbers:
Gasket type: BSHG-06 & BSHG-10
Specifications:
**Port Size:
BSHG-06: 3/4”
BSHG-10: 1-1/4”
**Max. Flow Liter/min
BSHG-06: 250
BSHG-10: 500
**Weight
BSHG-06: 7.8kg
BSHG-10: 12.6kg
** Bolt Size
BSHG-06: M16x80x4pcs
BSHG-10: M20x90x4pcs
**Max. pressure: 350 kgf/cm2
**Pressure Adjustment Range from 7 – 210 (kgf/cm2)
