Parameters (The technical specification only for reference, it can be customized)
Model Voltage Rated Current Max flow Max water head Power
V A L/H G/H M ft w
ZK30A-0406 4.5 0.10 100 26 0.6 2.0 0.45
ZK30A-0507 5 0.11 110 29 0.7 2.3 0.55
ZK30A-0609 6 0.11 120 32 0.9 3.0 0.66
ZK30A-0712 7 0.13 160 42 1.2 3.1 0.91
ZK30A-0913 9 0.14 170 42 1.3 4.2 1.26
ZK30A-1215 12 0.18 200 53 1.5 4.8 2.16
ZK30A-1219 12 0.22 210 55 1.9 6.2 2.64
ZK30A-1223 12 0.23 220 58 2.3 7.5 2.76
ZK30A-1225 12 0.26 230 61 2.5 8.1 3.12
ZK30A-1227 12 0.29 235 62 2.7 8.8 3.48
ZK30A-1230 12 0.35 240 63 3.0 9.7 4.20
Remarks The current above is open outlet current, when contact to circulation system the current will cut down to 55%~70% of Rated current.
Model Voltage Rated Current Max flow Max water head Power
V A L/H G/H M ft w
ZK30A-0406 4.5 0.10 100 26 0.6 2.0 0.45
ZK30A-0507 5 0.11 110 29 0.7 2.3 0.55
ZK30A-0609 6 0.11 120 32 0.9 3.0 0.66
ZK30A-0712 7 0.13 160 42 1.2 3.1 0.91
ZK30A-0913 9 0.14 170 42 1.3 4.2 1.26
ZK30A-1215 12 0.18 200 53 1.5 4.8 2.16
ZK30A-1219 12 0.22 210 55 1.9 6.2 2.64
ZK30A-1223 12 0.23 220 58 2.3 7.5 2.76
ZK30A-1225 12 0.26 230 61 2.5 8.1 3.12
ZK30A-1227 12 0.29 235 62 2.7 8.8 3.48
ZK30A-1230 12 0.35 240 63 3.0 9.7 4.20
Remarks The current above is open outlet current, when contact to circulation system the current will cut down to 55%~70% of Rated current.
