Product ID: AE Series

Single - Stage Directly Motor Coupled Vertical Reducer

Single - Stage Directly Motor Coupled Vertical Reducer
Type: Reducer, Worm Gear Reducers, Gear Reducer
Fixing with the headless screw
Complete with the motor disc for motor (1/8HP~30HP) installing directly
The input bore diameter and output shaft size can be modified as per customers' requests.

Click here for details.

• Standard models: 50#~100#
• the exact model number depends upon the application of working situation.
• Standard ratio: 1/5~1/60
• The special ratios like 1/8, 1/25, 1/70, and the less ratios are also available by customization.
• The standard shaft axis :S45C
• Standard shaft axis out of S45C, which can be substituted by SCM4, SCM21, etc as per customers' requests or with heat treatment processing for enhanced hardness and endurance

• Minimum Order: Negotiable
• TEL: 886-4-25343640
• FAX: 886-4-25343641
• E-mail: geartech@ms69.hinet.net
