DIN Screws Header
Product ID: D4
| d1 | M2.5 | M3 | (M3.5) | M4 | M5 | M6 |
|---|---|---|---|---|---|---|
| d2 | 4.7 | 5.6 | 6.5 | 7.5 | 9.2 | 11 |
| Tolerance zul. Abw. | +0~-0.3 | +0~-0.3 | +0~-0.36 | +0~-0.36 | +0~-0.36 | +0~-0.43 |
| f | 0.6 | 0.75 | 0.9 | 1 | 1.25 | 1.5 |
| k (max.) | 1.5 | 1.65 | 1.93 | 2.2 | 2.5 | 3 |
| r1 | 5 | 6 | 7 | 8 | 10 | 12 |
| r2 (max.) | 0.7 | 0.8 | 0.95 | 1 | 1.3 | 1.6 |
| GroBe | 1 | 1 | 2 | 2 | 2 | 3 |
| m (min.) | 2.7 | 3.1 | 4.2 | 4.5 | 5.3 | 6.8 |
| Eindringtiefe max. | 1.3 | 1.7 | 1.74 | 2.04 | 2.77 | 3.03 |
| Kreuzschlitz der Lenre | 1.6 | 2 | 2.24 | 2.54 | 3.27 | 3.53 |
| r2 (max.) | 0.25 | 0.3 | 0.35 | 0.4 | 0.5 | 0.6 |
| Punch Code | DMO M2.5 | DMO M3 | DMO M3.5 | DMO M4 | DMO M5 | DMO M6 |
