Application:
Household Appliance / Oven / Heater / Office Machine / Laminator / Lighting / Ice Mixer / Rotating Stand for CCTV Camera / 3D rotating Billboard / X'mas Tree Rotating Stand / Toys / Game Machine
Household Appliance / Oven / Heater / Office Machine / Laminator / Lighting / Ice Mixer / Rotating Stand for CCTV Camera / 3D rotating Billboard / X'mas Tree Rotating Stand / Toys / Game Machine
Specifications
- Rated Voltage: 24,100,110 ~ 120,200 ~ 240VAC
- Power Frequency: 50 / 60Hz
- Input Power: 3 ~ 6W
- Number of Poles: 12P
- Rotor Speed: 500 / 600RPM
- RPM: 1-200RPM
- Stall Torque: 15Kg-cm at 5 RPM
- Rotation: CW, CCW, Reversing
- Operation Temperation: -10°C ~ 60°C
- Insulation Strength: AC 1500V - 1Min
- Insulation Class: A Class
- Lead Wire: 1007 x AWG22# x 200mm
Features
- UL Approval and CE Marking Approval
- Brass Gears
- SECC Motor Cover
- ODM, OEM welcomed
- Low noise
- High Torque
Main Products
Synchronous Motor
