standard spray booth
Spray booth (BZB-8400) :
Outside Size (mm): 7000*5560*3430
Front Door(mm): 3000(w)*2600(H)
Inside Size(mm): 6900*4000*2800
Total Power(kw): 16
1) Cabin System:
Wallboard: EPS (epispastics polystyrene)Colorful Steel Skin Boards, 50mm Thick, Tongue & Groove Style, Compound Construction, Aluminum-alloy Frame. Anti-flame and Heat-Insulation
Basement: Full Grid, Adjustable Height, Galvanized Steel Sheet Construction, Three Embossed Steel Ramps
2) Air Circulation System:
Inlet Fan Model: YDW 4.5L1 Blower capacity: 24000m3/h
Outlet Fan Model: YDW 5.6S Blower capacity:15000m3/h
4) Purification System :
Capture granules larger than 10um. Filtering rate reaches 98%. TSP is less than 1.2 mg/m3
5) Heating System :
Italy Riello RG5S diesel burner, 260000Kcal/h, 20N damper motor, 2 sets quick dryer.
Heating exchanger, stainless steel , argon arc welding, heat exchange rate 85%.
Max temp : 80 degree, heating time : 4-6min(20-60 degree) fuel consumption: 6-8kg/vehicle
6) Lighting System :
ceiling light:24pcs 36w Philips lamp: bottom light: 16pcs 36w Philips : 900Lux
7) Controlling System :
spray & baking switch , light switch, emergency stop, breakdown alarm.
Outside Size (mm): 7000*5560*3430
Front Door(mm): 3000(w)*2600(H)
Inside Size(mm): 6900*4000*2800
Total Power(kw): 16
1) Cabin System:
Wallboard: EPS (epispastics polystyrene)Colorful Steel Skin Boards, 50mm Thick, Tongue & Groove Style, Compound Construction, Aluminum-alloy Frame. Anti-flame and Heat-Insulation
Basement: Full Grid, Adjustable Height, Galvanized Steel Sheet Construction, Three Embossed Steel Ramps
2) Air Circulation System:
Inlet Fan Model: YDW 4.5L1 Blower capacity: 24000m3/h
Outlet Fan Model: YDW 5.6S Blower capacity:15000m3/h
4) Purification System :
Capture granules larger than 10um. Filtering rate reaches 98%. TSP is less than 1.2 mg/m3
5) Heating System :
Italy Riello RG5S diesel burner, 260000Kcal/h, 20N damper motor, 2 sets quick dryer.
Heating exchanger, stainless steel , argon arc welding, heat exchange rate 85%.
Max temp : 80 degree, heating time : 4-6min(20-60 degree) fuel consumption: 6-8kg/vehicle
6) Lighting System :
ceiling light:24pcs 36w Philips lamp: bottom light: 16pcs 36w Philips : 900Lux
7) Controlling System :
spray & baking switch , light switch, emergency stop, breakdown alarm.
