Model
W-8

Type
Line array system

Frequency Response
45Hz-20KHz±3dB

Directivity index(DI)
12(±2)1.2KHz-16KHz

Power handling
LF 2×600W(RMS)2×1200W(PEAK)

MF 600W(RMS)1200W(PEAK)

HF 200W(RMS)400W(PEAK)

Sensitivity
LF 104dB(1W1M)

MF 107dB(1W1M)

HF 111dB(1W1M)

MaxS.P.L
LF 135dB(PEAK/1M)

MF 135dB(PEAK/1M)

HF 134dB(PEAK/1M)

LF section
2×12" (310mm)neodymium woofer

75mm(3in) coil

Nominal impedance
8 ohm

MF section
4×6.5" (170mm)neodymium MF

50mm(2in)coil

Nominal impedance
8 ohm

HF section
2×3"neodymium compression driver

with 75mm titanium diaphragm

Nominal impedance
16 ohm

Output section
3-channel

Dispersion pattern
110°H×7.5°V

Finish
Water-proof,wear-resistant textured black paint

Array design
Arrays of less than 3×W-8 will

provide poor dispersion control and

are neither recommended nor supported

Speaker cables
LF 1(+)1(-) 2(+)2(-) MF 3(+)3(-) HF 4(+)4(-)

Rigging system
Please refer to the W-8 user

manual before an
