Function:
1.Lock:Door closed up.
2.Stop at opening:Revolving wing stops at opening position.
3.Stop at closing:Revolving wing stops at closing position.
4.Continuous rotation:Revolving door slows down when no pedestrian,resumes to normal speed when sensors detect people approaching.
5.Manual revolving clockwise:For cleaning and checking.
6.Manual revolving anti-clockwise:For cleaning and checking.
1.Sliding door:For high traffic flow.
2.Balanced door:Maximum opening as panic breakout even for access of oversize objects.
3.Emergency stop:Door stops quickly when emergency.
4.Handicap:Door revolves at low speed for access of the disabled.
5.Backwards moving upon touching obstacles:200mm
Technical Data:
Power supply: 220V/AC ±10% 50Hz
Power consumption:
-Revolving door motor:270Wx2=540W
-Sliding door motor: 100Wx2=200W
Lighting: 12V/AC 600W
High speed adjustment range: 1- 4 r.p. m
Low speed adjustment range: 0.5- 2.5 r.p.m
Ambient temperature range: -15℃ - 50
1.Lock:Door closed up.
2.Stop at opening:Revolving wing stops at opening position.
3.Stop at closing:Revolving wing stops at closing position.
4.Continuous rotation:Revolving door slows down when no pedestrian,resumes to normal speed when sensors detect people approaching.
5.Manual revolving clockwise:For cleaning and checking.
6.Manual revolving anti-clockwise:For cleaning and checking.
1.Sliding door:For high traffic flow.
2.Balanced door:Maximum opening as panic breakout even for access of oversize objects.
3.Emergency stop:Door stops quickly when emergency.
4.Handicap:Door revolves at low speed for access of the disabled.
5.Backwards moving upon touching obstacles:200mm
Technical Data:
Power supply: 220V/AC ±10% 50Hz
Power consumption:
-Revolving door motor:270Wx2=540W
-Sliding door motor: 100Wx2=200W
Lighting: 12V/AC 600W
High speed adjustment range: 1- 4 r.p. m
Low speed adjustment range: 0.5- 2.5 r.p.m
Ambient temperature range: -15℃ - 50
