Specifications

MODEL
E2002V-PD

Display method
Vacuum fluorescent display

Display color
Blue green

Number of character
20 columns x 2 lines

Brightness
700 cd/m2

Character font
5 x 7 dot matrix, comma, decimal point

Character size
9.2 x 5.25 mm

Character pitch
8.3mm

Code Page
PC-437 / 850 / 860 / 863/ 865, Slavonic, Russian, Katakana

Emulation
ESC/POS

Interface
RS-232 (with path through function), USB (optional)

Power Supply
12V DC

Power Consumption
4.5W

MTBF
25,000 hours

Dimensions
230(W) x 100(H) x 42(D) mm

Viewing angle
±30 degrees

Rotation angle
Maximum 270 degrees

Weight
0.9 Kg
