Input Frequency: 3.4-4.2GHz
L.O. Frequency: 5.15GHz ± 1MHz
Stability: ± 2MHz(-40 ℃ - +70 ℃)
Output Frequency: 950-1750 MHz
Conversion Gain: 65 dB (TYP)
L.O. Phase Noise: -55 dBc/Hz@1KHz
-85 dBc/Hz@1KHz
-105 dBc/Hz@1KHz
Gain Flatness: ±0.5dB/36 MHz
Noise Figure: 17°K/15°K
Input V.S.W.R 2.5:1
Output V.S.W.R 2.5:1
Local Leakage At Input: -45 dBm
Image Rejection: 50dB
Output power: +5 dBm (AT 1 Db COMPRESSION)
Cross Polar Isolation: 23Db MIN
Dc Supply Voltage: 11-14.5 V (V), 15.5-22V (H)
Supply Current: 130 mA (MAX)
Operating Temperature: -40 ℃ ~ +70 ℃
Relative Humidity: 0%~95%
RF Input Connector “F”Type Female
Output Impedance: 75 OHMS
