Purpose : for washing ores of ferrous and non-ferrous metals of size 4-100 mm; kimberlite ores of size up to 5 mm

Effective area of separation, m2 2,5
Maximum efficiency:
- ores of size 4-100 mm, t/h
with rotor discharges
without rotor discharges
- kimberlite ores of size up to 5 mm, t/h 80
Nominal width of jigging compartment, mm 1250
Excessive air pressure , MPa 0,025-0,055
Pulsation frequency, Hz 0,5-4,0
Overall dimensions, mm:
- with rotor discharges
Length 2680
Width 2480
Height 4160
-without rotor discharges
Length 2400
Width 2410
Height 4160
Mass ( without SPTA, protective coatings and electrical equipment ), kg not more 4700
