Tubing head
Tubing head, we can supply
Tubing head, as per API standard.
Tubing Head
1.Pressure:2000-20000 psi
2.Top flange:7 1/16-11"
3.Bottom flange:9 - 13 5/8"
4.Side bore:46,52,65
Tubing Head
Tubing spool is used for hanging tubing and sealing the annular space between casing and tubing, features with the following:
1. Secondary seal between tubing hanger and adapter hanger can be ring, grease injection BT seal or metal-metal seal;
2. Metal-metal seals, special elastomer seals, or metal+special elastomer seals are set between tubing hanger and tubing head;
3. Tubing hanger for tubing head has straight type seat bore and 45°cone of hanging shoulder, with strong loading ability;
4. Complete with lubricator and sealing test port;
5. Secondary seal mechanism is set at the bottom flange, which can be seal, grease injection BT seal or metal seal;
6. Tubing hanger and tubing head adapter flange can be penetrated through by cable and be provided with subsurface safety valve which can control pipeline interface, exhaust pipeline interface, chemical agent injecting interface. When it is not used, it can be installed blind plugging.
7. The two ends of tubing hanger can be set with tubing thread or gas seal ing button and in the center it can ser with SPV thread as required
8. Top flanges are provided with locking screw;
9. The connection type of side outlet is bolted flange with VR thread for valve-replacement operation.
Tubing head, as per API standard.
Tubing Head
1.Pressure:2000-20000 psi
2.Top flange:7 1/16-11"
3.Bottom flange:9 - 13 5/8"
4.Side bore:46,52,65
Tubing Head
Tubing spool is used for hanging tubing and sealing the annular space between casing and tubing, features with the following:
1. Secondary seal between tubing hanger and adapter hanger can be ring, grease injection BT seal or metal-metal seal;
2. Metal-metal seals, special elastomer seals, or metal+special elastomer seals are set between tubing hanger and tubing head;
3. Tubing hanger for tubing head has straight type seat bore and 45°cone of hanging shoulder, with strong loading ability;
4. Complete with lubricator and sealing test port;
5. Secondary seal mechanism is set at the bottom flange, which can be seal, grease injection BT seal or metal seal;
6. Tubing hanger and tubing head adapter flange can be penetrated through by cable and be provided with subsurface safety valve which can control pipeline interface, exhaust pipeline interface, chemical agent injecting interface. When it is not used, it can be installed blind plugging.
7. The two ends of tubing hanger can be set with tubing thread or gas seal ing button and in the center it can ser with SPV thread as required
8. Top flanges are provided with locking screw;
9. The connection type of side outlet is bolted flange with VR thread for valve-replacement operation.
