Conductor:24AWG Copper 0.51±0.02mm
Insulation:HDPE 0.92±0.06mm
Cores/Pairs:8/4
Sheath:5.2±0.1mm PVC/LSOH/PVC(UV)/PE
Elongation:Min. 300%
Temperature Range:-20 up to +75℃
Tensile strength:Min.1.68Kg/mm2
Conductor Resistance:Max.9.38Ω/100m
Resistance Unbalance:Max.2%
Insulation Resistance:Max.150Ω/Km
Mutual Capacitance:Max.5600pF/100m
Capacitance Unbalance:Max.330pF/100m
Impedance:100±15
Spark Test::2000v
Velocity of Propagation:67%
