Specifications

Worktable dimension:800*500 mm
Travel of X,Y,Z axes:400*350*300 mm
Max workpieces dimension:600*450 mm
Max workpieces weight:1000 kg
Travel of U,V axes:+/-30-60 mm
Diameter of elctrode:0.12~0.25 mm
Dimension of plant:1600*1200*2100 mm
Standard power supply:380V +/-10% / 50Hz / 2kVA

Control system

Communications Integrator(CI):RS232/NIC/USB
ISO code:3B/G code
File format:AUTOCAD DXF/IGES/AUTOP
