Technical Specification:
Max hose ID: 2" 6-spiral Hose
Theoretical Crimping Force(Ton):490
Max. Pressure (Mpa):28
Die Opening & Closing(mm):+/-44
Max. Opening (mm):140
Motor Size(Kw):4
Operating Voltage:380v-3Ph-50Hz
Full Crimping Circle (Seconds):13
Accuracy(mm):0.01 Max.
Standard dies:15,18,21,24,27,33,39,45,51,57,66,73
Un-even(mm):0.1 Max.
Weight(Kg):240(without oil)
Dimensions(Length×Width×Height):630×450×750(mm)
Max hose ID: 2" 6-spiral Hose
Theoretical Crimping Force(Ton):490
Max. Pressure (Mpa):28
Die Opening & Closing(mm):+/-44
Max. Opening (mm):140
Motor Size(Kw):4
Operating Voltage:380v-3Ph-50Hz
Full Crimping Circle (Seconds):13
Accuracy(mm):0.01 Max.
Standard dies:15,18,21,24,27,33,39,45,51,57,66,73
Un-even(mm):0.1 Max.
Weight(Kg):240(without oil)
Dimensions(Length×Width×Height):630×450×750(mm)
