FX-95 Technical Specification
 Max hose ID: 2＂ 4SP
 Crimping Force: 420 ton
 Die Opening & Closing : +/- 40mm
 Opening Without Dies: 136mm
 Motor: 4Kw
 Voltage: 380V-50Hz-3Phase
 Full Crimp Cycle: 10s
 Accuracy: 0.02mm
 Un-even: ≤0.1mm
 Weight: 200kg
 Die-sets Supplied: 15 19 23 27 31 36 41 47 53 58 67
 Dimensions (L×W×H): 630×450×800 (mm)
FX-95 Die Chart
Die No. Range(mm) Length(mm) Die No. Range(mm) Length(mm)
15 15-19 75 41 41-47 75
19 19-23 75 47 47-53 75
23 23-27 75 53 53-58 75
27 27-31 75 58 58-64 75
31 31-36 75 67 67-73 75
36 36-41 75
