Type: QDT9382TDP
Frame ( lenght X windth X height ) mm : 13600(13920) x 3000 x 1820, 1750,1880 (2460)
Weight (kg) : 11000
Nominal load (kg) :27000
Wheel base (mm): 9608+1232+1232
Axle Quantity : 3
Track (mm): 2300
Front Suspension/Back Suspension (mm) : -/968 (1288)
Plate Spring Quantity (front/back) : 10/10
Tyres : 11.00-20 12.00R20
Tyre Quantity : 12
(Specifications are subject to product improvement)
Frame ( lenght X windth X height ) mm : 13600(13920) x 3000 x 1820, 1750,1880 (2460)
Weight (kg) : 11000
Nominal load (kg) :27000
Wheel base (mm): 9608+1232+1232
Axle Quantity : 3
Track (mm): 2300
Front Suspension/Back Suspension (mm) : -/968 (1288)
Plate Spring Quantity (front/back) : 10/10
Tyres : 11.00-20 12.00R20
Tyre Quantity : 12
(Specifications are subject to product improvement)
Specifications
- Model:
- QDT9382TDP,QDT9210TDP,QDT9390TDS
- DIMENSION(mm)
- Length X Width X Height:
- 13600X3000X1820 12930X3000X2996
- 14380X3000X1820
- Loading Capacity: (Kg)
- 27000 12000 25000
- Front/Back suspension:
- -/968(1288) -/1398 -/1040
- Approach/ Departure angle(?:
- -/32(26) -/28 -/32
Features
- Wheelbase:
- 9608+1232+1232 9700+1232 11520+1220
- Wheel Tread: (mm)
- 2300 -/2200/2200 -/2395/2395
- Number of Tyre:
- 12 8 16
- Tyre Type:
- 11.00-20 10.00-20 8.25-15
- Number of Axles:
- 3 2 4
