"Product Information
Model: 500w
H2.7-500w Wind power Generator which features high efficiency and low rated wind speed introducing several patented technologies and some special materials. All of the wind generators are matched with wind-solar hybrid inverter controller, which can connect solar panel within 250w simultaneously. Please contact us for the detail
The off-grid wind power generator is matched with 2pcs 12VDC batteries in series, and on-grid system can connect to state grid.
Application
Well used in:
● Housing
● Telecommunications Station
● TV Transfer Station
● Monitoring Station (military, hydrology, observatory)
● Water-pumping Station
Techinal Parameter Rated power(W) 500
Maximum output power(W) 1000
Charging voltage (V) DC 24V
Blade quantity 3
Blade material GRP(glass fiber reinforced plastic)
Blade diameter(m) 2.7
Start-up wind speed (m/s) 3
Rated wind speed (m/s) 7
Rated rotating rate (r/min) 600
Wind energy utilizing ratio (Cp) 0.48
Generator output single-phase frequency conversion AC
Output AC frequency (Hz) 0~300
Rated charging current (A) 15
The maximum charging current (in a short time )(A) 25
Generator efficiency >0.78
Tower diameter(mm) Ф76*3*2000
Tower height(m) 6
Generator weight (kg) 6.5
Battery 12V 150Ah/200Ah 2pcs
"
Model: 500w
H2.7-500w Wind power Generator which features high efficiency and low rated wind speed introducing several patented technologies and some special materials. All of the wind generators are matched with wind-solar hybrid inverter controller, which can connect solar panel within 250w simultaneously. Please contact us for the detail
The off-grid wind power generator is matched with 2pcs 12VDC batteries in series, and on-grid system can connect to state grid.
Application
Well used in:
● Housing
● Telecommunications Station
● TV Transfer Station
● Monitoring Station (military, hydrology, observatory)
● Water-pumping Station
Techinal Parameter Rated power(W) 500
Maximum output power(W) 1000
Charging voltage (V) DC 24V
Blade quantity 3
Blade material GRP(glass fiber reinforced plastic)
Blade diameter(m) 2.7
Start-up wind speed (m/s) 3
Rated wind speed (m/s) 7
Rated rotating rate (r/min) 600
Wind energy utilizing ratio (Cp) 0.48
Generator output single-phase frequency conversion AC
Output AC frequency (Hz) 0~300
Rated charging current (A) 15
The maximum charging current (in a short time )(A) 25
Generator efficiency >0.78
Tower diameter(mm) Ф76*3*2000
Tower height(m) 6
Generator weight (kg) 6.5
Battery 12V 150Ah/200Ah 2pcs
"
Features
.small, light and high outputCertificate
