"Product Information
Model: 1kw
H-3.1-1kw Wind power Generator which features high efficiency and low rated wind speed introducing several patented technologies and some special materials. All of the wind generators are matched with wind-solar hybrid inverter controller, which can connect solar panel within 500w simultaneously. Please contact us for the detail
The off-grid wind power generator is matched with 5pcs batteries in series, and on-grid system can connect to state grid. Fuse Parameters of batteries and solar panels are 500V, 30A.
Application
Well used in:
● Housing
● Telecommunications Station
● TV Transfer Station
● Monitoring Station (military, hydrology, observatory)
● Water-pumping Station
Technical parameters
Rated power(W) 1000
Maximum output power(W) 2000
Charging voltage(V) DC 60V
Blade quantity 3
Rotor blade material GRP
Rotor blade diameter(m) 3.1
Start-up wind speed (m/s) 3.0
Rated wind speed (m/s) 9.0
Rated rotating rate (r/min) 500
Wind energy utilizing ratio (Cp) 0.45
Generator output single-phase frequency conversion AC
output AC frequency (Hz) 0~400
Rated charging current (A) 15
The maximum charging current (in a short time )(A) 30
Generator efficiency >0.8
Tower diameter(mm) Ф89X3.5×2000
Tower height(m) 8
Weight of generator (kg) 15
Battery 12V 150Ah/ 200Ah 5pcs
"
Model: 1kw
H-3.1-1kw Wind power Generator which features high efficiency and low rated wind speed introducing several patented technologies and some special materials. All of the wind generators are matched with wind-solar hybrid inverter controller, which can connect solar panel within 500w simultaneously. Please contact us for the detail
The off-grid wind power generator is matched with 5pcs batteries in series, and on-grid system can connect to state grid. Fuse Parameters of batteries and solar panels are 500V, 30A.
Application
Well used in:
● Housing
● Telecommunications Station
● TV Transfer Station
● Monitoring Station (military, hydrology, observatory)
● Water-pumping Station
Technical parameters
Rated power(W) 1000
Maximum output power(W) 2000
Charging voltage(V) DC 60V
Blade quantity 3
Rotor blade material GRP
Rotor blade diameter(m) 3.1
Start-up wind speed (m/s) 3.0
Rated wind speed (m/s) 9.0
Rated rotating rate (r/min) 500
Wind energy utilizing ratio (Cp) 0.45
Generator output single-phase frequency conversion AC
output AC frequency (Hz) 0~400
Rated charging current (A) 15
The maximum charging current (in a short time )(A) 30
Generator efficiency >0.8
Tower diameter(mm) Ф89X3.5×2000
Tower height(m) 8
Weight of generator (kg) 15
Battery 12V 150Ah/ 200Ah 5pcs
"
Features
.small, light, high outputMain Products
wind generator
