Specification
Item Specification
Nominal Capacity 100Ah
Nominal Voltage 48V
Max charge voltage 58.4V
Max Continuos Charge Current 100A
Max Continuos Discharge Current 100A
Charging cut-off current 3A
Charging cut-off voltage 40V
Communication
CAN&RS 485 or RS232
Recommended charge and
discharge battery body temperature
Charge:0~45℃
Discharge:-10~55℃
Humidity range 0 ~ 90 % RH (non-condensing)
Weight 64Kg
Executive Standard YD/T 2344.1-2011
Charge model CC CV
Shell Material Cold-roll steel sheets
Battery dimension (444*440*220 )±1mm
Our new arrival 48v 5kwh lithium battery solar storage lithium ion battery 10kwh
Item Specification
Nominal Capacity 100Ah
Nominal Voltage 48V
Max charge voltage 58.4V
Max Continuos Charge Current 100A
Max Continuos Discharge Current 100A
Charging cut-off current 3A
Charging cut-off voltage 40V
Communication
CAN&RS 485 or RS232
Recommended charge and
discharge battery body temperature
Charge:0~45℃
Discharge:-10~55℃
Humidity range 0 ~ 90 % RH (non-condensing)
Weight 64Kg
Executive Standard YD/T 2344.1-2011
Charge model CC CV
Shell Material Cold-roll steel sheets
Battery dimension (444*440*220 )±1mm
Our new arrival 48v 5kwh lithium battery solar storage lithium ion battery 10kwh
