Model:APMS-60-24
Technical Specs:
Output Parameters
Rated Output voltage: 24VDC
Rated Output Current:2.5A
Rated Output Power:60W Max
Efficiency>90%
Line Regulation:±0.5%
Load Regulation:±1.5%
Voltage tolerance:±3%

2. Input Parameters
Rated Input voltage:200-277VAC
Input voltage range:176-305VAC, 47-63hz
Input Current Max:0.5A
Inrush Current0.95
THD200Khours
Dimension:115(L)*64 (W)*37(H)mm
Packing: 0.55KG/PC, 350 x 310 x 260 mm, 24pcs /14.7Kg /0.02CBM/CTN

Model NO/input voltage/output voltage/output current/output power/Efficiency/ Dimension
APMS-60-24/200-277VAC/24VDC/2500mA/60W/88%/115x64x37mm
APMS-60-36/200-277VAC/36VDC/1666mA/60W/88%/115x64x37mm
APMS-60-48/200-277VAC/48VDC/1250mA/60W/88%/115x64x37mm
APMS-60-54/200-277VAC/54VDC/1100mA/60W/88%/115x64x37mm
