Model:APMS-150-24
Technical Specs:
Output Parameters
Rated Output voltage: 24VDC
Rated Output Current:6.25A
Rated Output Power:150W Max
Efficiency>92%
Line Regulation:±0.5%
Load Regulation:±1.5%
Voltage tolerance:±3%

2. Input Parameters
Rated Input voltage:200-277VAC
Input voltage range:176-305VAC, 47-63hz
Input Current Max:1.0A
Inrush Current0.95
THD200Khours
Dimension:180(L)*63 (W)*40(H)mm
Model NO/input voltage/output voltage/output current/output power/Efficiency/ Dimension
APMS-150-24/200-277VAC/24VDC/6250mA/150W/92%/180x63x40mm
APMS-150-36/200-277VAC/36VDC/4160mA/150W/93%/180x63x40mm
APMS-150-48/200-277VAC/48VDC/3125mA/150W/93%/180x63x40mm
APMS-150-54/200-277VAC/54VDC/2777mA/150W/93%/180x63x40mm
