1. Output current: 10A, 5A, 1A, 200mA, 40mA, 5mA, automatic setting.
2. Measurement range: 0.001Ω-1.6Ω (10A position)
0.03Ω-3.2Ω (5A position)
0.06Ω-16Ω (1A position)
0.1Ω-80Ω (200mA position)
0.3Ω-400Ω (40mA position)
100Ω-100kΩ(5mAposition)
3. Accuracy: 0.2%±2μΩ
4. Resolution: 0.1μΩ
5. Operating temperature: -20 ~ 40℃
6. Ambient humidity: ≤ 80%RH; no condensation
7. Operating power supply: Rechargeable DC lithium battery; AC220V mains
8. Dimensions: 323 * 270 * 140 mm
9. Total mass: 5.28kg
2. Measurement range: 0.001Ω-1.6Ω (10A position)
0.03Ω-3.2Ω (5A position)
0.06Ω-16Ω (1A position)
0.1Ω-80Ω (200mA position)
0.3Ω-400Ω (40mA position)
100Ω-100kΩ(5mAposition)
3. Accuracy: 0.2%±2μΩ
4. Resolution: 0.1μΩ
5. Operating temperature: -20 ~ 40℃
6. Ambient humidity: ≤ 80%RH; no condensation
7. Operating power supply: Rechargeable DC lithium battery; AC220V mains
8. Dimensions: 323 * 270 * 140 mm
9. Total mass: 5.28kg
