Key Features:

Frequency available with 125KHz, 134.2KHz
3.3V ~ 5V DC Power supply, UART-TTL interface
Compatible with ISO11784,11785 Standard , support FDX-B
R/W HITAGS 64, HITAGS 256, HITAGS 2048,Read only UID OF EM4100/4200, TK4100 cards
External antenna, reading range up to 5~7 cm
External LED&BUZ available( external driver circuit needed

Technical Parameters:

Electrical Specification
Power supply DC 3.3V
Power consumption < 45mA
Operation frequency 125KHz &134.2KHz
Baudrate 9600~115200 bit/s ( default 9600bps)
Interface UART TTL
Antenna External, stamp-hole
Reading range 50- 100mm (depends on tag and antenna size)

Mechanical Specifications
Dimension 25mmx16.5mmx2.8mm (LxWxH)


Supported Standard/ Tags
EM4100,EM4200, TK4100
ISO/IEC 11784/11785 HITAGS 64, HITAGS 256, HITAGS 2048

SDK information
Demo software Windows, C# program language
Files Comprotocol document
API document
User Manual
Demo.exe
