Technical Features:
DUty rating: S1
Number of poles: 4
Winding pitch: 2/3
Frames: 188
Phrase sequence:UVW
Powers: up tp 4000kVA
Frequency: 50Hz to 60Hz
Terminal: 6and 12 leads
Power Factor: 0.8 lagging
Voltage regulation: +/- 0.5%
Low voltage: 110V to 690V
Speed: 1500 rpm or 1800 rpm
High voltage: 3300V to 13800V
Maximum unbalance load: 25%
Direction of rotation: CW from drive end
Over-speed: 1.2 times notmal speed for 2 minutes
Harmonic distortion factor:
