Mode HV-680HT
Airball Cushion Feeder Yes
Max Cutting Size 680mm
Max Cutting Thickness 80mm
Min Cutting Size 30mm
Cutting Precise ±0.2mm
Pushing Paper Programmable
Pressing Paper Hydraulic + Mechanical Pedal
Display Touch Screen
Programmed Yes
Power 220v/110v±10% 50Hz(60Hz)2.5kw
Machine Weight 450kgs
Packing Size 1400*1150*1460mm
Characteristics
1.Double lead screws and ball screws for pushing paper
Double lead screws and ball screws for pushing paper platform without slot design, to make the pushing force more equal and durable, It matches up the servo motor control design, cutting precision is better, and increasing the speed of pushing paper.
2.Swing arm design of blade carrier patented technology
The design makes the roller slot not easy to wear and tear, and can adjust the gap of blade carrier to ensure cutting accuracy.
3.Inclined blade cutting patented technology
Any thick paper can be cut smooth and easily with inclined blade design.
4.Leak-Proof design
Mak
Airball Cushion Feeder Yes
Max Cutting Size 680mm
Max Cutting Thickness 80mm
Min Cutting Size 30mm
Cutting Precise ±0.2mm
Pushing Paper Programmable
Pressing Paper Hydraulic + Mechanical Pedal
Display Touch Screen
Programmed Yes
Power 220v/110v±10% 50Hz(60Hz)2.5kw
Machine Weight 450kgs
Packing Size 1400*1150*1460mm
Characteristics
1.Double lead screws and ball screws for pushing paper
Double lead screws and ball screws for pushing paper platform without slot design, to make the pushing force more equal and durable, It matches up the servo motor control design, cutting precision is better, and increasing the speed of pushing paper.
2.Swing arm design of blade carrier patented technology
The design makes the roller slot not easy to wear and tear, and can adjust the gap of blade carrier to ensure cutting accuracy.
3.Inclined blade cutting patented technology
Any thick paper can be cut smooth and easily with inclined blade design.
4.Leak-Proof design
Mak
Certificate
- CE
Main Products
paper cutting machine, perfect binding machine, roll laminator
