parker high flow filter
General Description
PHFK Series High Flow Filter Cartridge is made of diameter 6" and pleated design, with high-strength pp center core, outside to inside flow direction. Outer cage have two types: integral pp cage and polyester mesh.
Application:
● RO pre-filtration, desalination pretreatment and a variety of process water filtration;
● Power plant supplementary water, condensation water, coolant filtration;
● Biopharmaceutical industry pharmaceutical raw materials, solvents, water filtration;
● Petrochemical industry various solvents, quench water, brine and other chemicals filtration.
Performance Specifications:
Dimensions(nominal):
OD: 6" (152mm)
Length: 40"
Material of Construction:
Filter Media: PP, Glass fiber/polyester
Support/Drainage: PP, Polyester
End Caps: Glass Fiber Reinforced Polypropylene
Seals Material: NBR, EPDM, Viton
Filter Performance
Micron：1μm, 5μm, 10μm, 15μm , 20μm, 40μm, 70μm
Maximum operating temperature：Pleated Glass Fiber:
PHFK Series High Flow Filter Cartridge is made of diameter 6" and pleated design, with high-strength pp center core, outside to inside flow direction. Outer cage have two types: integral pp cage and polyester mesh.
Application:
● RO pre-filtration, desalination pretreatment and a variety of process water filtration;
● Power plant supplementary water, condensation water, coolant filtration;
● Biopharmaceutical industry pharmaceutical raw materials, solvents, water filtration;
● Petrochemical industry various solvents, quench water, brine and other chemicals filtration.
Performance Specifications:
Dimensions(nominal):
OD: 6" (152mm)
Length: 40"
Material of Construction:
Filter Media: PP, Glass fiber/polyester
Support/Drainage: PP, Polyester
End Caps: Glass Fiber Reinforced Polypropylene
Seals Material: NBR, EPDM, Viton
Filter Performance
Micron：1μm, 5μm, 10μm, 15μm , 20μm, 40μm, 70μm
Maximum operating temperature：Pleated Glass Fiber:
