General Description
PHFM High Flow Filter Cartridge is made of diameter 6.5" and pleated design with big flow area and dirt holding capacity. It can meet different flow requirements, with a wide range of chemical compatibility, can be applied to various fields.

Application:
RO pre-filtration, desalination pretreatment;
Power plant condensation water filtration;
Biopharmaceutical industry pharmaceutical raw materials, solvents, water filtration;
Food and Beverage process water treatment;

Dimensions(nominal)
OD: 6.5" (165mm)
Length: 20",40", 60"

Material of Construction:
Filter Media: PP, Glass fiber/polyester
Support/Drainage: PP, Polyester
End Caps: Glass Fiber Reinforced Polypropylene
Seals Material: NBR, EPDM, Viton

Filter Performance
Micron：1μm, 3μm, 5μm, 10μm , 15μm, 20μm, 50μm, 70μm
Maximum operating temperature：82℃
Maximum operating differential pressure: 3.44bar@82℃
Suggestion pressure for filter replacement: 2.5Bar@20℃
