Application:
RO pre-filtration, desalination pretreatment;
Power plant condensation water filtration;
Paints, coatings, petrochemical, refining;
Microelectronics, films, fibers, resins.

Performance Specifications

Dimensions(nominal):
OD: 50mm, 60mm ID: 25mm, 28mm Length: 70"(1778mm), 60" (1524mm)

Parts Material
Filter Media: Polypropylene, Cotton, Glass Fiber
Support Core: Stainless steel 304/316

Filter Performance
Micron：1μm, 5μm, 10μm
Maximum operating temperature：85℃
Maximum operating differential pressure: 2.45Bar
Design Flow Rate: 2.9m³/h-3.2m³/h
Connection Type: Thread
Connection Thread: M33×1.5, M33×2, G1", 1 3/16〃-24 BSW
Bottom Thread: M6, M8, M10
