Type: PH3 Black SMD2020;
Pixel Pitch: 3mm;
Dimensions (W*H): 192mm*96mm;
Resolution (W*H): 64*32;
Pixel Density: 2048dots/module;

Pixel Density 111111 dots/㎡
Brightness ≥1500 cd/m²
Viewing Distance 1- 100 m based on the pixel distance and your screen size.
Drive Mode 1/16 scanning
Viewing angle H150° V120°
Frame Frequency / Refresh Rate >60Hz/s 800 Hz/s
Working Humidity 10%-95%
Power Supply 220V,380V OR 110V/50Hz,60Hz
Continual Running Time >72 Hours
Life-span (typical use) 100,000 Hours
Average No Failure Time >8,000 Hours
Working Temperature -20 to +50 Celsius degree
Grey Scale Recommend 4096 level (software adjustable from 2bit to 16bit)
Power consumption Average: 350W/㎡
Max: 1000 W/㎡
Display Colors 64G(under 4096 level gray scale)
Control Mode Video frequency Synchronic control
Color contrast ratio / temperature 1800：1
Symmetry of screen brightness ≥ 0.9 (low brightness/high brightness)
Surface Flatness screen surface: +/- 1mm, differe
