The oil industry, chemical industry,Electric power;
Hydraulic pressure system,Pneumatic system;
Energy and Water treatment system;
Automation equipment;
Industrial process control.
Performance parameters
Pressure range : -0.1~250MPa
Pressure mode : Gauge Pressure、absolute pressure
Output signal : 4~20mA , 0~10V or Optional
Accuracy(%FS) : 0.1 0.25 0.5
Nonlinearity(%FS) : ≤0.1 ≤0.25 ≤0.5
Hysteresis(%FS) : ≤0.1 ≤0.25 ≤0.5
Repeatability(%FS): ≤0.1 ≤0.25 ≤0.5
Zero drift (%FS/℃): ≤0.02
Temperature drift(%FS)≤0.02
Stability (%FS/Year): ≤0.25
Working voltage(V) : 12~36V DC(Standard:24V)
Working temperature(℃): -20~250℃
Overload capacity(%): 300
Life span: more than 9 million times pressure cycle
Load resistance (Ω): ≤750
Response time (ms): ≤1
Measurement of medium: Mediums compatible with 316L
Diaphragm material: 316L or the ceramic diaphragm
Housing material : 1Cr18Ni9Ti
Pressure interface: M20*1.5,G1/2,G
Hydraulic pressure system,Pneumatic system;
Energy and Water treatment system;
Automation equipment;
Industrial process control.
Performance parameters
Pressure range : -0.1~250MPa
Pressure mode : Gauge Pressure、absolute pressure
Output signal : 4~20mA , 0~10V or Optional
Accuracy(%FS) : 0.1 0.25 0.5
Nonlinearity(%FS) : ≤0.1 ≤0.25 ≤0.5
Hysteresis(%FS) : ≤0.1 ≤0.25 ≤0.5
Repeatability(%FS): ≤0.1 ≤0.25 ≤0.5
Zero drift (%FS/℃): ≤0.02
Temperature drift(%FS)≤0.02
Stability (%FS/Year): ≤0.25
Working voltage(V) : 12~36V DC(Standard:24V)
Working temperature(℃): -20~250℃
Overload capacity(%): 300
Life span: more than 9 million times pressure cycle
Load resistance (Ω): ≤750
Response time (ms): ≤1
Measurement of medium: Mediums compatible with 316L
Diaphragm material: 316L or the ceramic diaphragm
Housing material : 1Cr18Ni9Ti
Pressure interface: M20*1.5,G1/2,G
