Specification
Nominal Voltage 12V
Nominal Capacity (20HR) 4.5AH
Product Series Standby
Dimensions Length 90±2mm(3.54inches)
Width 70±2mm(2.75inches)
Container Height 100±3mm(3.93inches)
Total Height(with Terminal) 105±1mm(4.13inches)
Approx Weight 1.40 kg/3.08 lbs
Terminal F1/F2
Rated Capacity 4.6AH/0.23A (20HR,10.80V,25℃/77℉)
4.5AH/0.45A (10HR, 10.80V,25℃/77℉)
3.83AH/0.76A (5HR, 10.80V,25℃/77℉)
3.37AH/1.12A (3HR, 10.80V,25℃/77℉)
2.92AH/2.92A (1HR, 10.20V,25℃/77℉)
Max.Discharge Current 67.0A(5s)
Internal Resistance Approx 35mΩ
SHENZHEN XBATT ENERGY TECHNOLOGY CO., LTD.
Mob/Whatsapp/wechat: +86 18675582132
Web: www.szxbatt. com
Address: A Building, Anzhilong Industrial Park, Qinghu Street, Longhua District, Shenzhen
Nominal Voltage 12V
Nominal Capacity (20HR) 4.5AH
Product Series Standby
Dimensions Length 90±2mm(3.54inches)
Width 70±2mm(2.75inches)
Container Height 100±3mm(3.93inches)
Total Height(with Terminal) 105±1mm(4.13inches)
Approx Weight 1.40 kg/3.08 lbs
Terminal F1/F2
Rated Capacity 4.6AH/0.23A (20HR,10.80V,25℃/77℉)
4.5AH/0.45A (10HR, 10.80V,25℃/77℉)
3.83AH/0.76A (5HR, 10.80V,25℃/77℉)
3.37AH/1.12A (3HR, 10.80V,25℃/77℉)
2.92AH/2.92A (1HR, 10.20V,25℃/77℉)
Max.Discharge Current 67.0A(5s)
Internal Resistance Approx 35mΩ
SHENZHEN XBATT ENERGY TECHNOLOGY CO., LTD.
Mob/Whatsapp/wechat: +86 18675582132
Web: www.szxbatt. com
Address: A Building, Anzhilong Industrial Park, Qinghu Street, Longhua District, Shenzhen
Certificate
- CE MSDS
Main Products
battery, lead acid battery, AGM battery, GEL battery, lithium battery
