General description:
USB 3.0 is not only possess the high usability and flexibility of USB 2.0 ,but also make a qualitative leap in data rate-480Mbps of USB 2.0 to 5Gbps. Considering this property, the JPLY engineers decided to adopt and developed this new technology in the field of industrial camera.
Its specially designed for professional clients who both use camera with 5Mega or above and have strict requirement in capturing rate at the same time.


specialfications:
Image sensor

1/2.5" CMOS Colour/BW



-

Pixel dimension

2.2um x 2.2um



-

Scan method

Progressive



-

Sensitivity

1.4V/Lux-sec(550nm)



-

Frame rate

14fps@ 2592 x 1944, 30fps@ 1920 x 1080,
36fps@ 1280 x 960,ROI



-

Shutter

Electronic shutter



-

SNR

44dB



-

Spectral response

400nm~1100nm



-

Data interface

USB3.0 rate 5Gbps,18M cable



-

Power

DC 5V



-

Current

About 500 mA



-

White balance

One-time white balance/regional white balance



-

A
