1. Description of Oil-Free Pure Aluminum Rod Continuous Casting And Rolling Line(Aluminum CCR Lines)
Oil-free pure aluminum rod continuous casting and rolling line is used to produce aluminium rod of diameter 9.5mm, 12.5mm, 15mm, its productivity ranges from 2.5t to 5t per hour, from a bar cross-sectional area of 2400mm. The raw material can be aluminum ingot as well as molten aluminum.Rod quality exceeds ASTM, DIN, BS, JS and other internationally accepted quality standards.Almost level casting and automatic casting system ensures no turbulent current, and by our special design, the molten aluminum feeding to casting system is oxide-free.Oil-free coiling system with rollers makes it possible to produce oil-free aluminum rod without the use of grease, which can save production cost and make workshop clean.
2. Main Components of oil-free pure aluminum rod continuous casting and rolling mill(Aluminum CCR Lines)
Furnace, 5-wheel casting machine, front drive unit, hydraulic shears, supporting device for cast bar movement, continuous rolling mill, lubrication oil system for rolling mill, emulsion circulation system for rolling mill, cooling & lubricating system for aluminum rod, two-position coiler, electrical control system and so on.
3. Main technical parameter of Main Components of oil-free pure aluminum rod continuous casting and rolling mill(Aluminum CCR Lines)
Diameter of aluminum rod： Φ9.5mm,Φ12.5mm,Φ15mm
Production capacity： 2.5~5.0 t/h
Raw material： aluminium ingot/electrolytic aluminium
Furnace： aluminium ingot:vertical furnace+ round holding furnace
electrolytic aluminium: round holding furnace
Casting bar： 1500-2400
Weight of coiled rod： 1.5-2.5t
Oil-free pure aluminum rod continuous casting and rolling line is used to produce aluminium rod of diameter 9.5mm, 12.5mm, 15mm, its productivity ranges from 2.5t to 5t per hour, from a bar cross-sectional area of 2400mm. The raw material can be aluminum ingot as well as molten aluminum.Rod quality exceeds ASTM, DIN, BS, JS and other internationally accepted quality standards.Almost level casting and automatic casting system ensures no turbulent current, and by our special design, the molten aluminum feeding to casting system is oxide-free.Oil-free coiling system with rollers makes it possible to produce oil-free aluminum rod without the use of grease, which can save production cost and make workshop clean.
2. Main Components of oil-free pure aluminum rod continuous casting and rolling mill(Aluminum CCR Lines)
Furnace, 5-wheel casting machine, front drive unit, hydraulic shears, supporting device for cast bar movement, continuous rolling mill, lubrication oil system for rolling mill, emulsion circulation system for rolling mill, cooling & lubricating system for aluminum rod, two-position coiler, electrical control system and so on.
3. Main technical parameter of Main Components of oil-free pure aluminum rod continuous casting and rolling mill(Aluminum CCR Lines)
Diameter of aluminum rod： Φ9.5mm,Φ12.5mm,Φ15mm
Production capacity： 2.5~5.0 t/h
Raw material： aluminium ingot/electrolytic aluminium
Furnace： aluminium ingot:vertical furnace+ round holding furnace
electrolytic aluminium: round holding furnace
Casting bar： 1500-2400
Weight of coiled rod： 1.5-2.5t
