Technical Features of High-speed Sheathing Extruder

1.Use double flights and circular arc BM type screw with good plasticization and output capacity (PVC) 800~1000 kg/h.
2.Front and back two caterpillars; automatic force-control and stable running.
3.Multi-flow channel with good effect for making cable.
4.There is warm water circulating system at movable trough side to control the cable step by step and reduce cable stress.
5.PLC control the whole line with touch-screen operation

Technical Parameter of High-speed Sheathing Extruder

Type SPV65/25 SPV90/25 SPV120/25 SPV150/25 SPV200/25
Screw diameter (mm) 65 90 120 150 200
L/D ratio 25:1 25:1 25:1 25:1 25:1
Screw revolution speed(r/min) 10-100 10-100 8-80 6-73 4.5-40
Max. torque(Nm) 2100 7163 13130 25467 53055
Driving power(KW) 30 75 110 160 220
Heat control zones(body/head) 3/2 4/2 6/2 6/2 8/2
Total heating power(KW) 13.5 24 42 54 72
Max. Output(PVC)(kg/h) 100 240 400 600 1000
Overall size(mm) 2480×1400×
1850 3420×2320×1850 4036×2240×
2065 4720×2310×2100 6516×2920×
2625
