PB18-100
professional loudspeaker/ PA system/ stage speaker/ KTV speaker/ outdoor speaker
Product ID: PB18-100
Send Inquiry
* 1400 W continuous program power capacity
* 97dB Sensitivity 1w/1m
* 37Hz ~1800Hz frequency response range
* 4" inside/outside voice coil with OFC(Oxygen-free Copper) wire for improved power-handling and durability
* Optimized winding length for extended Xmax
* Forced air ventilation and 14mm top plate for minimum power compression
* Ideal for compact bass-reflex subwoofer application
————————————————————————————————1. Nominal Diameter: 18 inch
2.Rated Impedance: 8 ohm
3.Nominal Power handling: 700 watts
4.Program Power: 1400 watts
5.Sensitivity(lw/lm): 97 db
6.Frequency Range 37-1.8 k hz
7.Minimum Impedance(Zmin) : 6.9 ohm
8.Voice Coil Diameter : 4 inch
* 97dB Sensitivity 1w/1m
* 37Hz ~1800Hz frequency response range
* 4" inside/outside voice coil with OFC(Oxygen-free Copper) wire for improved power-handling and durability
* Optimized winding length for extended Xmax
* Forced air ventilation and 14mm top plate for minimum power compression
* Ideal for compact bass-reflex subwoofer application
————————————————————————————————1. Nominal Diameter: 18 inch
2.Rated Impedance: 8 ohm
3.Nominal Power handling: 700 watts
4.Program Power: 1400 watts
5.Sensitivity(lw/lm): 97 db
6.Frequency Range 37-1.8 k hz
7.Minimum Impedance(Zmin) : 6.9 ohm
8.Voice Coil Diameter : 4 inch
