Dual LED for 360-degree visibility
Stainless steel inner housing for high ANTI-RFI
Designed to comply with EN-54 standards
Two or four wire models optional
Sleek, low-profile housing design
Low power consumption, high precision and stability
Durable Sensor Head; Excellent smoke access
Power-off reset for 2 wire connection
Auto-reset or power-off reset optional for 4 wire connection
Easy Installation and maintenance
24V mode available
Operating Voltage:DC12V
Standby Current:≦15mA
Alarm Current:≦15mA
Detecting Area:80 square meter(with the installation height of 6m-12m), and 60 square meter (with the installation height less than 6m)
Alarm Output:Relay output (N.O/N.C) and LED flash
Installation Method:Ceiling Mounted
Operating Temperature:-10°C -- +55°C
Operating Humidity: ≦95%RH
Dimensions 104mm(Dia)x51mm(H)
Stainless steel inner housing for high ANTI-RFI
Designed to comply with EN-54 standards
Two or four wire models optional
Sleek, low-profile housing design
Low power consumption, high precision and stability
Durable Sensor Head; Excellent smoke access
Power-off reset for 2 wire connection
Auto-reset or power-off reset optional for 4 wire connection
Easy Installation and maintenance
24V mode available
Operating Voltage:DC12V
Standby Current:≦15mA
Alarm Current:≦15mA
Detecting Area:80 square meter(with the installation height of 6m-12m), and 60 square meter (with the installation height less than 6m)
Alarm Output:Relay output (N.O/N.C) and LED flash
Installation Method:Ceiling Mounted
Operating Temperature:-10°C -- +55°C
Operating Humidity: ≦95%RH
Dimensions 104mm(Dia)x51mm(H)
