Pneumatic Cylinder Honing machine and Vertical Honing Machine is a quality product from ABM MACHINES.
The cabinet of the machine is constructed out of 10 SW Gauge sheet. Material duly painted to make it
quite sturdy and durable. Pneumatic Cylinder honing machine gives a close dimensional accuracy and a
perfect cross hatch pattern in the bores of engine cylinder body and sleeve. in this model conventional
vitrified or abrasives are easily interchangeable liner movement from end to end is on linear bearings.
Stroke speeds are variable and controllable. It is very easy to dial at any RPM and rate at any time while
honing cradle of this machine can be indexed for precise alignment of inline and 60º or 90º Vs.

FEATURES
# The Hone Block is mounted on a sliding device to facilitate quick bore centering in a few seconds.
# All the operations of the machine have been designed to be controlled in an easy way.
# Incase of taper in the bore at the upper & lower portion, the hone can be set at the particular level.
# The machine is DUCO painted to give it an excellent look.
# This machine is completely noiseless in comparison with the Hydraulic one.
# The machine is box-type which avoids the wastage of cooling liquid.
# Due to its free flowing Honing Head, it can be adjusted left-Right / Up-Down in the cylinder, bore within
seconds.

APPLICATION AREA
# Automobile Industry.

STANDARD ACCESSORIES
# Heavy duty 2 HP, 3 phase Electric Motor.
# Hold Down Fixture for honing.
# With Mains Caps ON or OFF.
# Separate switches for upper and lower dwelling.
# One set of honing stones.
# High output pump and good quality filters.
# Good quality flexible coolant pipe.

OPTIONAL ACCESSORIES
# Complete range of hone heads (From 57 to 381 mm).
# Electric Invertor (1.5 Kw / 2 HP).
# Tools and Diamond hone head.
# Adjustable lamp fixture.
# Adjustable Block Fixture.
# Friction Feed Hone Adjustment in running position (From 68 to 140 mm).
# Counter meter.
# Load Meter.
