ITEM 0.5cm stripe
Composition 99.58%/0.42%% Polyster/ carbon fibre
Structure 1/2 twill 1.5cm interval of conductive yarn
Weight( g/㎡) 130
Width 60inch(150cm)
Surface resistance 108-1010 ohm/unit
Electrical Potential 0.4µ c/m2
Decay Time 1.0 sec
Air Permeability 30c.c/cm2/sec
Tensile Strength warp 820N weft 1590N
Tear Strength warp 4100gf weft 6250gf
Stripe Fabric Specification
Composition 99.58%/0.42%% Polyster/ carbon fibre
Structure 1/2 twill 1.5cm interval of conductive yarn
Weight( g/㎡) 130
Width 60inch(150cm)
Surface resistance 108-1010 ohm/unit
Electrical Potential 0.4µ c/m2
Decay Time 1.0 sec
Air Permeability 30c.c/cm2/sec
Tensile Strength warp 820N weft 1590N
Tear Strength warp 4100gf weft 6250gf
Stripe Fabric Specification
