Product Specifications Type ---Cylindrical Lithium Iron Phosphate Battery
Model------------------------------------------- LFP18650E-140
Dimension (Including shrink sleeve/label)
Diameter, d ----------------------------------18.1±0.2mm
Height, h --------------------------------------64.5±0.5mm
Mass----------------------- --------------------41g (Approx)
Nominal voltage -----------------------------3.65V
Capacity(0.2C discharge) C: Nominal-------1400mAh
Minimum----------------------------------------- 1400mAh
Maximum charge voltage-----------------3.65V
Maximum continuous charge current--------1400mA
Maximum discharge current Continuous----4200mA
Discharge cut-off voltage-----------------2.5V
Internal impedance)(23±2)---------------≤50mΩ
Model------------------------------------ LFP18650P-110
Dimension (Including shrink sleeve/label)
Diameter, d ----------------------------18.1±0.2mm
Height, h ---------------------------------64.5±0.5mm
Mass--------------39.5g (Approx)
