Product Specifications Type -----------------Normal Cylindrical Battery
Model-------------------------------------------- LFP14430E-040
Dimension (Including shrink sleeve/label)
Diameter, d ---------------------------------------------- 14.1±0.2mm
Height, h ------------------------------------------------- 42.5±0.5mm
Mass----------------------- ------------------------------- 16g (Approx)
Nominal voltage ------------------------------------------ 3.2V
Capacity(0.2C discharge) C: Nominal------------------- 400mAh
Minimum-------------------------------------------------- 400mAh
Maximum charge voltage-------------------------------- 3.65V
Maximum continuous charge current-------------------- 400mA
Maximum discharge current Continuous---------------- 1200mA
Discharge cut-off voltage--------------------------------- 2.5V
Internal impedance)(23±2)---------------------------- ≤80mΩ
Operation temperature Discharge-------------------------20-60
Charge------------------------------------------------------ 0-45
Storage temperature
non-condensing
Within 1month--------------------------------------------- 0-45
1-3months------------------------------------------------- 0-35
3-12months------------------------------------------------ 0-25
