Model & specification


WAW-100B


WAW-300B


WAW-600B


WAW-1000B




Max. test force (kN)


100


300


600


1000




Measuring range (kN)


2%-100%FS Can improve range to 0.4%-100% FS




Relative error toforce value (%)


≤±1


≤±1


≤±1


≤±1




Distance between compression surfaces (mm)


0-540


0-540


0-680


0-610




Max. distance between tensile jaws (mm)


0-590


0-590


0-630


0-650




Bending test pressed rolling distance (mm)


100-500


100-500


100-500


60-700




Clip diameter of round sample (mm)


Φ6-Φ20


Φ10-Φ32


Φ13-Φ40


Φ20-Φ60




Clip thickness of flat sample (mm)


0-15


0-15


0-30


0-40




Width of flat plate specimen (mm)


≤60


≤60


≤70


≤80




Size of shearing specimen (mm)


0-Φ10


0-Φ10


0-Φ20


0-Φ30




Effective distance
between the pillars (mm)


500


500


580


580




Piston stroke (mm)


150


150


180


180




Motor power (kW)


1.2


1.5


2.1


2.1




Main frame outline
dimension (mm)


805×520×1850


805×520×1850


950×630×2120


960×630×2220




Oil source control cabinet outline dimension (mm)


580×480×1000


580×480×1000


580×480×1000


580×480×1000




Weight (about) (kg)


1500


1800


2500


3000
