vandals resistance and rot resistance.,waterproofing IP66,DTMF,red color
Prevent sabotage Weatherproof phone with cover
The Weatherproof phone will be designed to work on Railway, metro, tunnel, etc. Housed in robust aluminium die case with spring loaded door, it will offer protection against the outdoor environment, vandals resistance and rot resistance.
The unit will meet all the latest European/UK standards for EMC and US FCC, telephony, waterproofing IP66, and lightening protection together with offering the level of performance and reliability demanded in such an environment.
*DTMF(Dual Tone Multi Frequency)
*Matching with most PABX,PBX and PAX systems.
Main Product features
1. Robust aluminium alloy die-cast body,
2. One or two button for emergency call and answer, keypad with 12key for normall out gong phone call or you can select 10key(0~9) with memory for programing 10 group of speed-dial.
3. Door cover: orient automatically and good self - closing, self-protection when open the door, convenient for use. safety design with patent.
4. Weather resistant to IP66 standard, service temperature range from:-30℃ to +75℃
5. Magnetic reed hook-switch with handset optional.
6. Telephone line powered. No external power or battery back up required.
7. Lightening protection to ITU-T recommendation K.21
8. Hearing aid compatible receiver, noise canceling microphone.
9. Selectable 7 minute time out, to release the line if the handset is left off hook, optional
10. Vandal resistant and tamper-resistant hardware,
11. Easy installation/ replacement
Certification:
EMC:
EN55022:2006 emissions
EN55024:1998 + A1:2001 immunity
Transients/Lightning
ITU-T recommendations K.21 (07/2003)
Ingress Protection:
GB4208-93
IP66
FCC
The Weatherproof phone will be designed to work on Railway, metro, tunnel, etc. Housed in robust aluminium die case with spring loaded door, it will offer protection against the outdoor environment, vandals resistance and rot resistance.
The unit will meet all the latest European/UK standards for EMC and US FCC, telephony, waterproofing IP66, and lightening protection together with offering the level of performance and reliability demanded in such an environment.
*DTMF(Dual Tone Multi Frequency)
*Matching with most PABX,PBX and PAX systems.
Main Product features
1. Robust aluminium alloy die-cast body,
2. One or two button for emergency call and answer, keypad with 12key for normall out gong phone call or you can select 10key(0~9) with memory for programing 10 group of speed-dial.
3. Door cover: orient automatically and good self - closing, self-protection when open the door, convenient for use. safety design with patent.
4. Weather resistant to IP66 standard, service temperature range from:-30℃ to +75℃
5. Magnetic reed hook-switch with handset optional.
6. Telephone line powered. No external power or battery back up required.
7. Lightening protection to ITU-T recommendation K.21
8. Hearing aid compatible receiver, noise canceling microphone.
9. Selectable 7 minute time out, to release the line if the handset is left off hook, optional
10. Vandal resistant and tamper-resistant hardware,
11. Easy installation/ replacement
Certification:
EMC:
EN55022:2006 emissions
EN55024:1998 + A1:2001 immunity
Transients/Lightning
ITU-T recommendations K.21 (07/2003)
Ingress Protection:
GB4208-93
IP66
FCC
Certificate
- CE/FCC/RoHS/IP66/ Patent/Comfirm by MII/EMC/EN55022:2006 /EN55024:1998 + A1:2001 /ITU-T /GB4208-93
