PROFILES:
Jelly candy machine is an advanced continuous plant for making different sizes of jelly candies. It’s an ideal equipment which can produce out good quality products with the saving of both the manpower and space.
PROCESSING CHART:
Melting sugar  storage tank  high speed mixer  syrup pump  depositing & moulding  cooling  packing  final products
Technical Parameter:
Capacity 150KG/H; 300KG/H
Steam Consumption 150KG/H; 300KG/H
Steam Pressure Needed 0.5-0.8MPa
Total Power 16.2KW
Depositing Speed 55N/MIN
Total Power 2KW; 3KW
Weight 1600 KG; 1800KG
Dimension 2000*1500*2100; 2000*1800*2100 MM
Machine Frame 10mm thickness A3 carbon Steel.
Shell 304 stainless steel. Thickness 1.5mm
Hopper 316 stainless steel; Thickness 1.5mm
Storage tank and pipes 316 stainless steel. Thickness 1.5mm
Total Power 7KW; 8KW
Dimension 8800*560*2200mm; 8800*820*2200 MM
Main machine frame A3 carbon steel. 50*70*3 square tube
Top adopts 1.5mm stainless steel
Bottom and sid
