Camera Head
* CCD color 600 TV lines
* Camera head size Φ50 x 88mm for pipe Φ 100mm and up
* Image sensor 1/3 inch
* Self-levelling picture
* Field of view 90°
* Camera lighting 18 white LEDS
Monitor
*7 inch TFT LCD monitor
* Power supply DC 12V
DVR Control Box
* DVR power supply 12V DVR work current 200mA
* Storage medium SD card jack
* Li-on Battery power supply (18650 x 6 pcs)
* Charging time 5 hours, working time 6 hours
* Keyboard output
Cable Reel
* Stainless steel Cable Reel size 770 x 830 x 360 mm
* 120m Φ9 mm fiberglass rod push cable ( 60m optional)
Unit control carrying case
* ABS Carrying case size: 520mm x 435mm x 200mm
* Unit operating temperature: -10 to 50 degrees Celsius, RH 95% maximum
* Storage temperature: - 20 to 70 degrees Celsius, RH 95% maximum
