1Multifuction
2PLC control system
3Best quality
4Long operating life
5Little investment
Main Technical Specifications
Production per Mould: 10pcs/mould (Standard Block: 400x200x200mm)
52pcs/mould (Solid Block: 240x115x53mm)
36pcs/mould (Porous: 240x115x90mm)
36pcs/mould (Holland Brick: 200x100x60-80mm)
Cycle Time: 15-17 seconds
Production per Shift (8 Working Hours): Hollow Block (400x200x200mm): 16880-19200pcs
Solid Block (240x115x53mm): 87776-99840pcs
Porous (240x115x90mm): 60768-69120pcs
Holland Brick (200x100x60-80mm): 46944-51840pcs
Max. Vibrating Frequency: 3000-4500rolls/minute
Vibrating Force: 60-80 KN
Motors Power: 43 KW
Machine Dimensions: 7250X2500x2680mm (excluding electrical control box)
Pallet Size: 1080X860X23mm
Gross Weight: about 13.5T
Raw Materials: crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.
Applied Products: concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc.
Applied Fields: widely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc.
2PLC control system
3Best quality
4Long operating life
5Little investment
Main Technical Specifications
Production per Mould: 10pcs/mould (Standard Block: 400x200x200mm)
52pcs/mould (Solid Block: 240x115x53mm)
36pcs/mould (Porous: 240x115x90mm)
36pcs/mould (Holland Brick: 200x100x60-80mm)
Cycle Time: 15-17 seconds
Production per Shift (8 Working Hours): Hollow Block (400x200x200mm): 16880-19200pcs
Solid Block (240x115x53mm): 87776-99840pcs
Porous (240x115x90mm): 60768-69120pcs
Holland Brick (200x100x60-80mm): 46944-51840pcs
Max. Vibrating Frequency: 3000-4500rolls/minute
Vibrating Force: 60-80 KN
Motors Power: 43 KW
Machine Dimensions: 7250X2500x2680mm (excluding electrical control box)
Pallet Size: 1080X860X23mm
Gross Weight: about 13.5T
Raw Materials: crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.
Applied Products: concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc.
Applied Fields: widely used in buildings, road pavings, squares, gardens, landscaping, city constructions, etc.
